Setting up and connecting the refrigerator HiPro
20
•
Maintain a minimum distance of 20 mm between the cooling unit and the rear
wall.
•
Keep objects clear of openings in the housing or installation structure (such as
ventilation slots, etc.).
7.2 Setting up the refrigerator in a freestanding position
Observe the following information if you wish to set up the refrigerator freestanding
on the floor:
•
Position the refrigerator horizontally. Use a water level to check this.
7.3 Installing refrigerator in cabinetry
Observe the following instructions if you wish to install the refrigerator in cabinetry:
•
Set up the refrigerator so that both device feet lie on the storage surface.
•
Air must be able to circulate without any hindrance (fig. 3, page 4).
•
Only the cooling unit may extend into the ventilation duct.
•
The air in the ventilation duct may not be heated by other heat sources.
Proceed as follows (fig. 4, page 5):
➤ Attach the reflector for the door opening monitor (optional).
➤ Screw the device feet in place.
7.4 Changing the door hinge
You can also change the hinge of the door, so that it opens to the left rather than the
right.
I
With an existing LED for the door opening monitor, proceed as follows:
➤ Pull the LED out.
➤ Lay the cable in the guide.
➤ Insert the LED on the other side again.
NOTE
The LED of the door opening monitor (optional) must always be located
opposite the door hinge.
