HiPro Setting up and connecting the refrigerator
19
6.1 Control elements on the refrigerator
6.2 Control elements outside the refrigerator
7 Setting up and connecting the
refrigerator
7.1 Instructions for installing the refrigerator
Observe the following when installing the refrigerator:
•
Install the refrigerator so that the warm air produced can easily flow away (either
upwards or to the sides, fig. 3, page 4).
No. in
fig. 1, page 2
Explanation
1 Interior light
2 LED of the door opening monitor (optional)
3Shelf
4 Lower door rack
5 Upper door rack
No. in
fig. 2, page 3
Explanation
1 Remote control for door opening monitor and temperature regula-
tion (optional)
Description in
fig. 3, page 4
Explanation
A Cold intake air
B Heated exhaust air
C Condenser
D Clearance above the refrigerator if exhaust air can not adequately
circulate upwardly or at the side
HiPro3000_4000_6000_Vision-IO-16s.book Seite 19 Dienstag, 27. November 2018 4:24 16
