Dometic NRX Series - 7.3 Compressor and error indicator LED; 7.4 Operation mode indicator LEDs

NRX0120TPEN
No. Explanation
5
Operation mode button
6 Interior lighting
Cooling level indicator LEDs
Cooling Level 5
Cooling level 4
Cooling level 3
Cooling level 2
7
Cooling level 1
8 Operation mode indicator LEDs
Compressor and error indicator LED
The compressor and error indicator LED displays the operating status of the compressor or indicates an error:
Color Description
White Compressor on
Orange Compressor off
Orange (flashing) Error (Error indication)
Operation mode indicator LEDs
The operation mode indicator LEDs display the following setting options:
Symbol Description
ECO mode:
Operation with reduced energy -consumption.
Cooling level 1 – 3
QUIET mode:
Operation with reduced noise level.
Cooling level 1 – 4
PERFORMANCE mode:
Cooling level 1 – 5
FREEZER mode:
Operation with frozen compartment removed. Cools down the complete interior of the refrig-
erator to – 9 °C (15.8 °F) at ambient temperature.
15
