Optimum cooling performance is provided at ambient temperatures between 16 °C (60.8 °F)… 43 °C (109.4 °F)
and at a maximum humidity of 90 %.
This product is only suitable for the intended purpose and application in accordance with these instructions.
This manual provides information that is necessary for proper installation and/or operation of the product. Poor in-
stallation and/or improper operating or maintenance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product resulting from:
• Incorrect installation, assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product specifications.
7 Technical description
The refrigerator is a compressor refrigerator.
The model is factory fitted with a frozen compartment, which can be removed and reinstalled.
The refrigerator door has a latching mechanism to protect it during transport.
All materials used in the refrigerator are compatible for use with foodstuffs.
Description of the device
Fig. on page3
No. Explanation
1 Door shelf
2 Bottle shelf
3 Crisper
4 Cabinet shelf
5 Control panel with display
6 Frozen compartment
7 Door latch for ventilation
Control and display elements
Fig. on page3
No. Explanation
1 IR door opening sensor
2
ON/OFF button
3
Cooling level setting button
4 Compressor and error indicator LED
