Dometic NRX Series User Manual

4445103632 13
EN
NRX0035–0130(C), NRX0050–0080(T) and
NRX1035–1130(S): The model is factory fitted
with a frozen compartment, which can be
removed and reinstalled.
The refrigerator door has a latching mechanism to
protect it during transport.
All materials used in the refrigerator are compatible
for use with foodstuffs.
Description of the device
Control and display elements
Compressor and error indicator LED
The compressor and error indicator LED displays
the operating status of the compressor or indicates
an error:
Operation mode indicator LEDs
The operation mode indicator LEDs display the fol-
lowing setting options:
No in
fig. 1,
page 3
Explanation
1 Door shelf (only NRX0035–0130[C],
NRX0050–0080[T], NRX1035–1130[S]
and NRX0080–0130[E])
2 Bottle shelf
3 Condensate drain
4 Crisper (only NRX0035–0130[C],
NRX0050–0080[T] and NRX1035–
1130[S])
5 Cabinet shelf
6 Control panel with display
7 Frozen compartment
(only NRX0035 – 0130[C], NRX0050 –
0080[T] and NRX1035–1130[S])
8 Door latch for ventilation
No in
fig. 2,
page 3
Explanation
1 IR door opening sensor
2
ON/OFF button
3
Cooling level setting button
4 Error and warning indicator LED
5
Operation mode button
6 Interior lighting
7 Cooling level indicator LEDs
Cooling Level 5
Cooling level 4
Cooling level 3
Cooling level 2
Cooling level 1
8 Operation mode indicator LEDs
Color Description
White Compressor on
Orange Compressor off
Orange
(flashing)
Error (chapter “Error indication” on
page 19)
Symbol Description
ECO mode:
Operation with reduced energy
consumption.
Cooling level 1 – 3
QUIET mode:
Operation with reduced noise level.
Cooling level 1 – 4
PERFORMANCE mode
Cooling level 1 – 5
FREEZER mode (only NRX0035–0130[C],
NRX0050–0080[T] and NRX1035–
1130[S]):
Operation with frozen compartment
removed. Cools down the complete
interior of the refrigerator to – 6 °C
(21 °F).
No in
fig. 2,
page 3
Explanation
