Dometic PLB40 Instruction Manual

EN
Using the appliance PLB40
12
✓ The symbol lights up.
✓ The display shows the charging status.
Charging with the smart alternator, 12 V accessory socket or solar panel
➤ Connect the charge cable to the connection socket (fig. 2 9, page 3).
➤ Connect the DC plug to the DC inlet Anderson socket on battery side.
✓ The symbol lights up the battery state of charge as a percentage.
✓ The display shows the charging status.
➤ If charging the battery pack with a solar panel, observe the following require-
ments:
– Use without a solar controller:
Ensure that the solar panel outputs between 8 – 25 V DC and a maximum
charging current of 10 A.
– Use with a solar controller:
Ensure the solar charger does not need a counter voltage from the battery
side to start charging. Ensure that the maximum charging current is 10 A
(check with the solar panel manufacturer).
6.4 Checking the charge level
➤ Press the power button (fig. 2 1, page 3).
✓ The display shows the battery state of charge as a percentage.
✓ The symbol flashes when the battery capacity is below 20%.
6.5 Connecting consumer devices
fig. 2, page 3
➤ Open the cap for the desired device:
–USB devices (3)
–2-pin 12VDC socket outlet (4)
–12VDC socket (5)
➤ Insert your device’s plug into the corresponding socket.
✓ The symbol and the related output symbol light up.
3/%2VERRN6HLWH0RQWDJ1RYHPEHU

Dometic PLB40 Specifications

General

Battery Type	Lithium Iron Phosphate (LiFePO4)
Capacity	40 Ah
Voltage	12.8 V
Charging Options	AC, DC, Solar
Warranty	2 years
Operating Temperature	-20°C to +60°C
Cycle Life	2000 cycles at 80% Depth of Discharge
Protection	Overcharge, Over-discharge, Short-circuit
USB Ports	2 (5V/2.4A each)
