PerfectPower Technical description
11
The device is equipped at delivery with galvanic isolation. For the safe operation of
multiple consumers, it is essential that a circuit breaker (residual current circuit
breaker) is built into the socket distribution circuit and the grounding bridge is set in
the inverter.
I
The inverter can be switched on manually or using a remote control.
Cooling is provided by a fan and is load-dependent.
7.1 Control elements
I
Front view (fig. 1, page 3)
NOTE
Note when connecting devices with an electrical drive (such as power
drills and refrigerators), that they often need more power than is stated
on the type plate.
NOTE
The version for continental Europe is pictured.
No. Description
1 Grid: This LED lights up if the inverter is supplied with external 230 V mains
power; the priority circuit is active.
2 Connection for the external 230 V power supply
3 Circuit breaker: Fuse
4 230 Vw output
5 POWER: This LED lights up when the inverter is switched on.
6 OLP: This LED lights up when the consumers connected draw too much
electricity.
7 UVP: This LED lights up when battery capacity is too weak.
8 OVP: This LED lights up when the input voltage is too high.
PP1000-PP2000--IO-16s.book Seite 11 Mittwoch, 3. August 2016 6:19 18
