Installing the refrigerator RCD10.5
12
4.1 Choosing an installation location
A
When installing the refrigerator, note the following:
• Ensure that the floor is solid and level.
Park the vehicle horizontally for this purpose.
• The refrigerator must be installed so that:
– easily accessible for service work
– easy to uninstall and install
– can be easily removed from the vehicle
• In campervans an undercounter unit can be installed with the door pointing in the
direction of travel, as long as it is installed next to the sliding door and behind the
co-driver’s seat.
• The refrigerator must be installed in a recess so that it stands secure when the
vehicle is in motion. Note the dimensions in fig. 1, page 3
and fig. 3, page 4
for this purpose.
Note the following recess dimension (fig. 2, page 4):
• The refrigerator must be installed with a minimum distance of 5 mm from the floor
to ensure that the door can be opened properly (fig. 3, page 4).
– Make sure that no carpets interfere with the free movement of the door.
– Avoid placing the refrigerator directly on the floor.
NOTICE! Damage hazard
• The refrigerator may not be installed in the rear of mobile homes with
the door pointing in the direction of travel.
• Leave the device in a vertical position for at least 3 hours before start-
ing up for the first time.
RCD10.ES, RCD10.5ET RCD10.XES, RCD10.5XET
Refrigerator height (A) 1283 mm 1283 mm
Refrigerator width (B) 523 mm 523 mm
Refrigerator depth (C)
(excludes control knob
5 mm)
550 mm 605 mm
Recess height (H) 1286 mm 1286 mm
Recess width (W) 528 mm 528 mm
Recess depth (D) 568 mm 623 mm
