RCD10.5 Installing the refrigerator
13
4.2 Installing the condensate drain
Condensation can form inside the refrigerator due to frequent door opening, incor-
rectly stored food or food that is stored when it is too warm. Condensation must be
drained with a constant slope.
Install the condensate drain as follows:
➤ Run the condensation water hose from the refrigerator through an opening in the
floor which goes outside.
4.3 Connecting the power supply
A
1. Determine the required cross section of the cable in relation to the cable length
according to fig. 4, page 5.
2. Connect the cables to the AMP connector of the refrigerator (fig. 5, page 5).
3. Connect the other ends of the cables to the
12 Vg power supply:
– rd (red): with a fuse protection (10 A) fitted to the positive (+) pole
– bk (black): to the negative (–) pole
The electrical power supply must be connected by a qualified electrician
who has demonstrated skill and knowledge related to the construction
and operation of electrical equipment and installations and has received
safety training to identify and avoid the hazards involved.
NOTICE! Damage hazard
• To avoid voltage loss and therefore a drop in performance, the cable
should be kept as short as possible and should not be interrupted if
possible. For this reason avoid additional switches, plugs or power
strips.
• Before connecting check whether the operating voltage and the bat-
tery voltage correspond (see data plate).
• Ensure that the polarity is correct when connecting the
12 Vg power
supply.
