Technical description RCD10.5XES
EN
10
7.1 Compo nen ts
No. in fig. 1, page 10 Description Quantity
1 Freezer compartment 1
2 Freezer compartment shelf 1
3 Control and display elements 1
4 Refrigerator shelf 3
5 Refrigerator compartment 1
6 Fruit and vegetable section 1
7 Freezer compartment door 1
8 Refrigerator door 1
9 Top door bin 2
10 Bottom door bin with bottle holder 1
9
7
8
10
4
1
3
2
6
5
1
