Dometic RM 5330 Installation Manual

EN
RM5310, RM5330, RM5380 Installing the refrigerator
79
6.3 Creating air inlets and outlets
I
➤ Create an air inlet and an air outlet in the exterior wall with a size of
451 mm x 156 mm. Observe the instructions while doing so, see chapter
“Preparing for installation” on page 77.
If the ventilation grille of the air inlet cannot be installed flush with the floor of
the installation recess, you must install an air inlet in the floor:
➤ Behind the refrigerator, in the area of the gas burner, create an air inlet in
the ground with a diameter of at least 40 mm (fig. 4 4, page 4). The air
supply pipe must lead directly to the outside. That allows escaping
unburned gas to escape outside.
➤ Protect the end of the hole with a deflector to prevent mud or dirt getting
in while the vehicle is driving (fig. 6, page 5).
NOTE
At high ambient temperatures, the refrigerator can only provide
its maximum cooling capacity if the best possible air supply and
discharge has been provided.

Dometic RM 5330 Specifications

General

Noise level	- dB
Climate class	SN
Total net capacity	65 L
Total gross capacity	70 L
Lamp type	LED
No Frost (fridge)	-
Fridge net capacity	60 L
Fridge interior light	Yes
Door hinge	Left
Product color	Black, Grey
Appliance placement	Freestanding
Refrigerating medium	R717
Freezer position	Top-placed
Freezing capacity	- kg/24h
Freezer net capacity	5 L
Storage time during power failure	- h
Current	0.54 A
Power source	Gas/Electric
Connected load	125 W
Gas consumption	270 g/24h
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Package depth	543 mm
Package width	523 mm
Package height	845 mm
Package weight	27000 g

Weight and Dimensions

Depth	474 mm
Width	486 mm
Height	821 mm
Weight	22000 g
