Dometic RM 5330 Installation Manual

EN
Inserting the door decoration RM5310, RM5330, RM5380
82
8 Inserting the door decoration
A
The door decoration must have the following dimensions:
 RM5310: 532±1 x 453±1 x max. 3.8–3 (h x w x d in mm)
 RM5330: 740 x 453.5 x max. 3.8–3 (h x w x d in mm)
 RM5380: 740 x 453.5 x max. 3.8–3 (h x w x d in mm)
Proceed as follows:
➤ Remove the door (see chapter “Changing the door hinge” on page 81).
➤ Remove the three bolts on the bottom of the door frame (fig. o 1,
page 9).
➤ Take off the door strip (fig. p, page 9).
➤ Insert the new decoration in the opening (fig. q 1, page 9).
➤ Put the door strip back in.
➤ Screw the three bolts back in again.
➤ Put the door back in (see chapter “Changing the door hinge” on page 81).
If you placed the refrigerator on its side to insert the decoration:
➤ Wait for an hour before putting the refrigerator into operation.
NOTICE! Beware of damage
Only ever place the refrigerator on its side, never on its back.
The cooling unit could be damaged otherwise.

Dometic RM 5330 Specifications

General

Noise level	- dB
Climate class	SN
Total net capacity	65 L
Total gross capacity	70 L
Lamp type	LED
No Frost (fridge)	-
Fridge net capacity	60 L
Fridge interior light	Yes
Door hinge	Left
Product color	Black, Grey
Appliance placement	Freestanding
Refrigerating medium	R717
Freezer position	Top-placed
Freezing capacity	- kg/24h
Freezer net capacity	5 L
Storage time during power failure	- h
Current	0.54 A
Power source	Gas/Electric
Connected load	125 W
Gas consumption	270 g/24h
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Package depth	543 mm
Package width	523 mm
Package height	845 mm
Package weight	27000 g

Weight and Dimensions

Depth	474 mm
Width	486 mm
Height	821 mm
Weight	22000 g
