EN
RM5310, RM5330, RM5380 Connecting the refrigerator
85
Connect the refrigerator as shown in fig. t, page 11 (without lighting)
and fig. u, page 12 (with lighting):
230 Vw:
Connect the refrigerator to a 230 Vw mains socket with the mains plug.
12 Vg:
Observe the following cable cross sections:
< 6 m (in the interior): 4 mm
2
> 6 m (in the interior): 6 mm
2
Cables laid over the shaft (Caravan only): 2.5 mm
2
Secure the power supply line for the heating element
(connection 3/4) with a 16 A fuse, and the power supply line for
the lighting (connection 5/6) with a 2 A fuse.
Lay the power supply line for the heating element (connection 3/4) via a
ignition-controlled relay to prevent the battery from accidentally being
discharged completely when the engine is switched off (fig. s, page 10).
Item Description
1 Heating cartridge battery
2 Connection cable 12 Vg
3 Earth, battery, heating element
4 Positive, battery, heating element
5 Positive, lighting
6 Negative, lighting
7 Reed contact (sensor circuit)
8 Galvanometer
9 LED lighting, battery
10 Thermocurrent adapter
11 Heating cartridge, mains
12 Connection cable 230 Vw
13 On the housing
