4.12 Changing the decor panel
 Remove the door, see “ 4.11 Changing the
doorhang
”.
 Loosen three screws of the lower moulding
and remove trim moulding.
 Withdraw the decor panel by sliding it
downwards . Fit new panel and slide it
upwards as far as possible.
 Fit the trim moulding back in place.
 Fit the door on the hinge pin.
Model RM 5310
Decor panel dimensions :
Height Width Thickness
532 +/-1 mm 453 +/-1 mm max. 3,8 mm
Model RM 5330
Height Width Thickness
740 mm 453,5 mm max. 3,8 mm
Model RM 5380
Height Width Thickness
740 mm 453,5 mm max. 3,8 mm
18
Refrigerator operation
Fig. 41
Fig. 42
Fig. 39
1
3
Fig 40
2
4
Fig. 43
Fig. 44
4.13 Winter operation
In Winter, check regularly that the ventilation
grilles and the exhaust duct system (1) have
not been blocked by snow, leaves, etc.
When the outside temperature falls below
+10°C, the winter cover (2) should be fitted.
This protects the unit from excessively cold air
which could have adverse effects on the per-
formance of the unit.
You should also attach the winter cover if the
vehicle is taken out of service for a longer
period of time or while it is being cleaned from
the outside.
1
2

Dometic RM 5380 Specifications

General

Door hinge	Left
Product color	Black, Grey
Custom panel-ready	-
Appliance placement	Freestanding
Refrigerating medium	R717
Noise level	- dB
Climate class	SN
Total net capacity	75 L
Total gross capacity	80 L
Lamp type	LED
Fridge net capacity	70 L
Fridge interior light	Yes
Freezer position	Top-placed
Freezer net capacity	5 L
Current	0.54 A
Power source	Gas/Electric
Connected load	125 W
Gas consumption	270 g/24h
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	- kWh
Package depth	543 mm
Package width	523 mm
Package height	845 mm
Package weight	29000 g

Weight and Dimensions

Depth	474 mm
Width	486 mm
Height	821 mm
Weight	24000 g
