INSTALLATION INSTRUCTIONS
GENERAL INFORMATION
The installation, servicing and gas installation must be per-
formed by an authorised/qualied person. The refrigerator
must be installed in accordance with the manufacturers in-
stallation instructions, local gas tting regulations, municipal
building codes, electrical wiring regulations, AS5601.2 “Gas
Installations” and any other statutory regulations.
PACKAGING
The packaging of this appliance is design to withstand the
transportation from the factory to the point where it will be
installed in the recreational vehicle.
Before starting to install the appliance, please, make sure all
parts of the packaging have been removed, so there will not
be anything left that may come into contact with heat parts of
the appliance or obstruct the combustion exhaust gases or the
air movement around the cooling unit.
VENTILATION REQUIREMENTS
The installation shall be made in such a manner as to separate
the combustion system from the living space of the mobile
home or recreational vehicle. Proper installation requires one
lower fresh air intake and one upper exhaust vent.
We recommend tting the Dometic ventilation system, which
is specially developed by Dometic for this purpose. The ven-
tilation kits must be installed and used without modication.
An opening toward the outside at oor level in the refrigera-
tor compartment must be provided for ventilation of heavier-
than-air fuel gases. The lower vent of the recommended kits
is provided with proper size openings. The ow of combus-
tion and ventilating air must not be obstructed.
The lower side vent provides an adequate access opening
for ready serviceability of the burner and control manifold
of the refrigerator. This should be centred on the back of the
refrigerator.
CLEARANCES
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIAL
inch mm
Top
G
0 0
Side
K
0 0
Bottom
L
0 0
Rear
M
1 25
M
G
KK
L
If the lower grille is not at oor level where leaking gas can
escape, a 40 mm hole to the outside should be made in the
oor of the recess to drain any unburned gas to the outside.
Fit the hole with wire mesh and an angled plate to protect it
from stones, mud etc.
MINIMUM VENTILATION REQUIREMENTS
Optional ventilation hole
minimum 40 mm diameter
Optimal
top vent height
is no lower than
top of the
cabinet.
min. clearance 10 mm
max. clearance 25 mm
Notice: If the design of the vehicle does not allow you to
install the top exhaust vent directly above the condenser of
the refrigerator (what Dometic recommends):
“Minimum top vent height is 746 mm (top of upper vent
opening)”
lowered vent it is required
that the deflector plate (1)
is installed so that it
touches the leading
bottom edge of the
1
Ventilation System (Not Included)
Ventilation components are:
- 1x AS1625 vent kit (top & bottom vents with frames)
- 1x TP (includes 1x tee piece & 1x extension)
- Extra extensions may be required depending on the
height of refrigerator and vent height.
S1625 vent kit TP Kit TPX
Extension
