3
FIG. 1
12V DC
Cover,
Reigniter
Power module
cover
Flexible cord
Drain water hose
12 volt
Terminal block
Inlet fitting
Manual gas
shutoff valve
Burner jet
Screw for protection cover
Protection
cover
Flue baffle
Heater
FIG. 2
D
B
ON
OFF
AC
GAS
CHECK
AES
AUTO
COLD
1
2
3
4
5
COLDEST
CLC
LAC
AC GEF
12 3 4 5
Refrigerator control panel
LEGEND 2-WAY AES Model
1. Main Power Button ON/OFF
2. AES/AUTO/GAS Mode Selector Button
3. Temperature Selector Button
4. Climate Control Button
5. Low Ambient Control Button
A. AC Mode Indicator Lamp
B. AES/AUTO Mode Indicator Lamp
C. GAS Mode Indicator Lamp
D. CHECK Indicator Lamp
E. Temperature Indicator Lamps
F. Climate Control Indicator Lamp
G. Low Ambient Indicator Lamp
