Dometic RMDX21 User Manual

EN
Installing the refrigerator RMDX21, RMDX25
26
6.4 Installing the ventilation grille
➤ Ensure the installation frame is water resistant (fig. 0, page 5).
➤ Insert the installation frame and screw it down tightly (fig. a, page 5).
Use all the fixing holes for this.
➤ Fit the ventilation grille (fig. b, page 6).
➤ Insert the slider and lock the ventilation grille with it (fig. b, page 6).
6.5 Install the roof vent
➤ Ensure the installation frame is water resistant (fig. d, page 6).
➤ Insert the installation frame and screw it down tightly (fig. e, page 6).
Use all the fixing holes for this.
➤ Insert the hood and screw it down tightly (fig. f, page 6).
No. in
fig. 9, page 5
Description
1Slider
2Ventilation grille
3Installation frame
No. in
fig. c, page 6
Description
1Hood
2Installation frame

Dometic RMDX21 Specifications

General

Type	Absorption
Climate Class	SN
Energy Source	12V, 230V, Gas
Input Voltage	12V DC, 230V AC
Refrigerant	Ammonia
