RMDX21, RMDX25 Technical data
35
See fig. y, page 17
Using a fridge movement switch to add 12 Vg to the D+ connection wire,
only when the vehicle is moving. The Anderson plug connection must keep
the house battery fully charged.
House battery recharged by vehicle.
The D+ is turned on and off via an optional fridge movement switch.
See fig. z, page 17
Anderson plug recharging the house battery via a power diode. The D+ wire
can only get a 12 V signal when the battery is being charged.
House battery recharged by vehicle.
The D+ is turned on and off by the vehicle starting and stopping.
8Technical data
RMDX21, RMDX25
Voltage: 230 Vw / 50 Hz
12 Vg
Capacity – total:
Capacity – freezer compartment:
190 l
30 l
Power consumption: 250 W (230 Vw)
170 W (12 Vg)
Power consumption: 4.2 kWh/24 h (230 Vw)
340 Ah/24 h (12 Vg)
Gas consumption: 420 g/24 h
Climatic class: T
Noise emission: 0 dB(A)
Dimensions H x W x D
without flange:
with flange:
fig. 1 A, page 2
fig. 1 B, page 2
Weight: 47 kg
Inspection/certification:
