RMDX21, RMDX25 Installing the refrigerator
29
Installing the new door panel and trim on framed door model
Proceed as follows (fig. n, page 10):
➤ Push the new panel upwards in the door as far as the stop.
➤ Push the new panel downwards into the door.
➤ Pull the new panel into the door trim still installed.
➤ insert the door trim again.
✓ The door trim is secure once it clicks into place.
Removing the door panel from frameless door model
Proceed as follows (fig. o, page 11):
➤ Push the old panel upwards as far as the stop.
➤ Pull the old panel out of the door.
Installing the new door panel on frameless door model
Freezer compartment door (fig. p, page 12):
➤ Push the new panel upwards in the door as far as the stop. Make sure that
the new panel fits the door at the left and right.
➤ Push the new panel downwards into the door.
Refrigerator door:
➤ Push two spacers downwards into the door, if necessary (fig. q,
page 12).
➤ Push the new panel upwards in the door as far as the stop. Make sure that
the new panel fits the door at the left and right (fig. r, page 13).
➤ Push the new panel downwards into the door (fig. r, page 13).
