RML9430, RML9431, RML9435 Using the refrigerator
31
➤ Undo the hinge pin (fig. o, page 10) and position it on the other side
(fig. p, page 10).
➤ Turn the door by 180° (fig. q, page 10).
➤ Place the door on the hinge pin.
➤ Tighten the hinge screw at the top door hinge.
➤ Replace the control panel and screw it down tightly.
7.17 Replacing the door panel
A
Proceed as follows (fig. r, page 10):
➤ Remove the door trim carefully. It is only stuck on and held by small
hooks (A).
➤ Remove the old panel sideways from the door (A).
➤ Slide the new panel into the opening (B).
➤ Replace the door trim (B).
✓ The door trim is properly fitted once it clicks into place.
If you have laid the refrigerator on its side to insert the panel:
➤ Wait a few minutes before you switch on the refrigerator.
NOTICE! Beware of damage
Only ever lay the refrigerator on its side and never on its back.
Otherwise the unit may be damaged.
