Installing the refrigerator RMV5301, RMV5305
18
If the ventilation grille of the air inlet vent cannot be installed flush with the floor of the
niche, you need to install an inlet vent in the floor:
➤ Make an air inlet vent in the floor (fig. 5, page 4) behind the refrigerator near the
gas burner. The vent pipe must lead directly outside. This allows leaking
unburned gas to escape outside.
➤ Shield the end of the opening with a deflector to prevent sludge or dirt from get-
ting inside while driving (fig. 5, page 4).
6.4 Installing the ventilation grille
LS200
LS230
Proceed as follows (fig. 9, page 6):
➤ Ensure the installation frame is water resistant (A).
➤ Insert the installation frame and screw it down tightly (B).
➤ Insert the ventilation grille and lock it in place (C).
No. in
fig. 7, page 5
Description
1 Installation frame
2 Ventilation grille
3 Winter cover
No. in
fig. 8, page 5
Description
1 Installation frame
2 Ventilation grille
3 Winter cover
