EN
Connecting the refrigerator RMV5301, RMV5305
22
➤ Connect the refrigerator according to fig. e, page 10:
AC power
➤ Connect the refrigerator with the mains plug to an AC socket.
DC power
Please note the following cable sizes:
– < 6m (interior): 4mm
2
– > 6m (interior): 6mm
2
– Connections D+ and S+: 1 mm
2
– Cable fed via drawbar (caravans only): 2.5 mm
2
Item Description
1 AC heating cartridge
2 AC power connection cable
3 Earth AC power
4 Ionisation
5 Ignition
6Burner
7 DC heating cartridge
8 LED lighting
9 Gas input
10 Gas output
11 Gas valve
12 DC power outlet
13 Gas valve supply line
A Optional connections to DC power outlet
B Negative terminal (–) DC permanent supply for electronics
C Positive terminal (+) DC permanent supply for electronics
D Connection D+ (only for RMV5305)
E Connection S+ (only for RMV5305)
F Positive cable of the heating cartridge
G Earth cable of the heating cartridge
