Dometic ROLLER Series - Fitting the guide wire versions; Fitting the side track versions; Electrical installation; Key to circuit diagrams

EN
Installation Rollerblind Powered
10
7.6 Fitting the guide wire versions
➤ Proceed as shown:
– BR leaflet: fig. 0 to fig. c
– MP leaflet: fig. 5 to fig. 9
– CA leaflet: fig. 5 to fig. 0
➤ Fix the hold down according the chosen option:
– Dome mounted hold down (A) (BR leaflet: fig. a, MP leaflet: fig. 7,
CA leaflet: fig. 7)
– Flush mounted hold down (B) (BR leaflet: fig. b, MP leaflet: fig. 8,
CA leaflet: fig. 8)
– Extended guide wire hold down (C) (BR leaflet: fig. c, MP leaflet: fig. 9,
CA leaflet: fig. 9)
7.7 Fitting the side track versions
➤ Proceed as shown:
– BR leaflet: fig. d to fig. e
– MP leaflet: fig. 0 to fig. a
– CA leaflet: fig. 0 to fig. a
7.8 Electrical installation
Proceed as follows:
➤ Check the voltage of the blind (see cable label).
➤ Decide on the routing of the motor wire.
➤ Choose a location for the control device.
➤ Mount the control device at the chosen location.
➤ Connect the blind according to the circuit diagrams for 12 Vg/24 Vg or
230 Vw (see DIAGRAMS leaflet).
Key to circuit diagrams (see DIAGRAMS leaflet)
Manual switch: fig. 4
Item Description
1 Fused power supply
(fuse rating: 2 A for 12 Vg, 1 A for 24 Vg, 1 A for 230 Vw)
2 Switch
