RUA5208X, RUA6408X, RUA8408X Installing the refrigerator
15
– Push the bottom trim piece with the four plugs (fig. a 1) into the holes on the
front frame of the refrigerator.
– Snap the three catches (fig. a 2) into the holes under the bottom frame of
the refrigerator.
6.3 Making air inlet and outlet vents
I
➤ Make a cut out in the wall to fit the LS300 for the upper and lower vent system,
see chapter “Preparing the installation” on page 6.
➤ If the lower ventilation grille can not be installed flush to the floor, make an air inlet
vent in the floor (fig. b, page 16) behind the refrigerator near the gas burner.
NOTE
At high ambient temperatures, the refrigerator can only provide its max-
imum cooling capacity if the optimum ventilation has been provided.
