RUA5208X, RUA6408X, RUA8408X Connecting the refrigerator
27
Item Description
1 Connection cable for AC connection
2 Heater 240 V AC
3 Earth for CU
4 Protective Earth
5 Electrode
6Outer fan 1
7 Fan thermostat
8Outer fan 2
9 Ignition port
10 Power module
11 Control button
12 Display
13 Inner fan
14 LAC and defrost heater
15 Frame heater (RUA6208X, RUA8408X only)
16 Gas valve
17 Temperature sensor
18 Lamp
19 Door sensor
20 Gas inlet
21 12 V DC heater
22 Relay
23 12 V DC vehicle battery connection
24 Thermostat
25 D+ to alternator connection
26 12 V DC house battery connection
27 Thermofuse
