RUA5208X, RUA6408X, RUA8408X Installing the refrigerator
9
•
The outer wall must be fitted with one air inlet ventilation grille (fig. 3 3a,
page 8) and one outlet ventilation grille (fig. 3 3b, page 8) so that the heat
generated can be easily released to the outside:
– Lower air inlet vent LS300 must be installed flush to the vehicle floor.
– Upper air outlet vent LS300 must be installed with the bottom of the vent no
lower than equal to the top of the refrigerator cabinet, the bottom of the top
vent can be higher than the cabinet.
•
Fit an air deflection plate (fig. 3 6, page 8) above the condenser so that the heat
does not accumulate in the vehicle.
•
Put insulation wool (fig. 3 1, page 8) on top and sides of the cabinet.
•
If the lower ventilation grille of the air inlet vent cannot be installed flush to the
floor, an additional vent (fig. 3 7, page 8 and fig. b, page 16) must be pro-
vided in the floor for releasing any possible gas leakage.
•
The distance between the refrigerator and the rear wall must be at least 10 mm.
Pos. in fig. 3,
page 8
Description
1 Insulation wool on top and sides of cabinet
2 Recommended maximum clearance 25 mm
3 LS300 ventilation grille
4 Minimum height is equal to the height of the cabinet
5 Dometic gas flue kit 3776
6 Air deflection plate
7 Floor vent, min. 40 mm (only required if lower air inlet vent is not flush to
the floor)
