RUC5208X, RUC6408X, RUC8408X Using the refrigerator
43
I
➤ Place the refrigerator door on soft material in order to prevent scratches.
➤ Remove the three screws from the lower hinge (2. in fig. A) and discard the old
hinge.
➤ Fix the new lower hinge (not included, see chapter “Accessories” on page 7) to
the new position with the three screws (3. in fig. A).
➤ Remove the cover from the lower hinge point (1. in fig. B).
➤ Install the cover on the opposite side (2. in fig. B).
➤ Rotate the locking catch on the latch side by 180 degrees to expose the fixing
screw.
NOTE
Carefully lift up the refrigerator door to prevent damaging the door
bushing.
