2
1.0 IDENTIFICATION
The identification plate of the machine is affixed outside
the plate casing (see fig. 1).
1.1 MANUFACTURER
DOMETIC ITALY srl
Via Virgilio, 3
47122 FORLI' - ITALY
P. IVA 00718330400
1.2 DEFINITIONS
In this handbook, three types of “safety graphics” are used
to point out different levels of danger or any other important
information:
DANGER
Draws attention to potentially dangerous situations which
may cause serious personal injury.
CAUTION
Draws attention to potentially dangerous situations which
may cause personal injury or material damage.
IMPORTANT
Draws attention to situations which may cause
malfunctioning or damage to the machine.
1.3 TRANSPORT - HANDLING - STORAGE
1.3.1 STORAGE CONDITIONS
The generator is protected against sudden impact by
suitable packing consisting of cardboard, polystyrene and
a wooden frame support.
The generator should be stored horizontally in a dry and
well-ventilated room.
1.3.2 WEIGHT
Gross weight (including packing):
Mod. 2500 .......................................... Kg 62
Mod. 4000 .......................................... Kg 114
Mod. 5500 .......................................... Kg 140
1.3.3 OVERALL DIMENSIONS
See figg. 2, 3, 4 :
Model
2500 4000 5500
A mm 470 660 700
B mm 535 740 --
C mm 565 770 --
D mm 320 475 515
E mm 315 355 510
F mm 260 310 --
G mm 27 62 --
H mm -- -- --
I mm 65 78 --
L mm 65 265 --
M mm 225 130 --
N mm 36 17 --
O mm 535 740 735
P mm 27 62 55
Q mm 260 310 370
X mm 590 780 770
Y mm 385 540 505
Z mm 335 380 550
Air intake area
cm
2
220 260
1.3.4 HANDLING
The packed generator can be handled by normal means of
lifting and transport.
Boxes are fitted with spacers which enable the use of
manual fork-lifts.
DANGER
Strictly observe the accident prevention precautions and
safety regulations during lifting and transport, and always
use machines
with a higher maximum capacity than the load to
be lifted.
2.0 INSTALLATION
2.1 AUTHORISED PERSONNEL
The generator shall be installed onto the vehicle (caravan,
motorhome or special vehicle) by authorised personnel
only, namely by skilled technicians or workshops, authorised
directly by DOMETIC ITALY srl
If the installation is carried out by non-authorized technicians
NOITALLATSNI "A" EPYT
NOITALLATSNI "B" EPYT
.MID GNINEPO
