Dometic TEC29 EV User Manual

EN
Technical description TEC29 EV, TEC29 EV LPG
16
Control elements in the control panel
The control panel is located on the generator behind the cover.
Control elements in the remote control
The remote control is installed in the vehicle interior.
No. in
fig. 2,
page 4
Description
1 Main switch Switches the generator to standby or no
function.
2 TEC29 EV only: Cut-out
switch
Electromechanical protection against over-
load.
3 TEC29 EV LPG only:
Main fuse
Triggers if the AC voltage overloads. Fuse
needs to be replaced if it has triggered.
4 TEC29 EV LPG only:
Battery charger fuse
Triggers if the AC voltage overloads. Fuse
needs to be replaced if it has triggered.
No. in
fig. 3,
page 4
Description
1 Display Shows the status reports.
2 On/Off switch P Switches the remote control on and off if the
main switch is at “I” or “1”.
Stops the generator.
3 START button Starts the generator if the remote control is
switched on and the main switch is at “I” or
“1”.
4 TEC29 EV only:
Petrol gauge
Lights up if the petrol goes into reserve.
5 Oil gauge Lights up if the oil level is too low in the
engine.
