VacuFlush Pedal-Flush Toilet Components
4 Components
(g.
3
, page 2) (g.
2
, page 2)
4.1 VacuFlush toilet
(g.
3
, page 2) (g.
2
, page 2)
Ref. Description
1 Seat and lid assembly
2 Ceramic bowl
3 Vacuum breaker
4 Water supply hose
5 Half clamp kit
6 Pedestal base
7 Flush pedal lever (cover not shown)
8 Water valve
9 Inlet screen
10 Pedestal cover
Refer to complete parts list (packed separately) for
additional information.
Ref. Description
A Vacuum status panel (DVS01 - option)
B VacuFlush status panel and power
switch (DVS02 - option)
C J series vacuum generator *
D S series vacuum pump *
E Vacuum tank *
* VacuFlush pedal-operated toilets use either a vacuum
generator or vacuum pump/vacuum tank combination.
Refer to vehicle manufacturer for your specic system
components.
4.1 Typical VacuFlush toilet system (marine)
(g.
4
, page 2)
Ref. Description
1 VacuFlush toilet
2 VacuFlush status panel
3 Holding tank status panel
4 Vacuum generator
5 Holding tank (waste)
Ref. Description
6 Vent lter
7 Discharge pump
8 Overboard discharge tting
9 Air vent tting
10 Dockside discharge tting
Some VacuFlush toilet systems combine the vacuum generator (4) and holding tank (5) into one unit (VacuFlush holding tank system).
Contact boat or vehicle manufacturer for complete information on your toilet system.
5 Specifications
5.1 Materials
Toilet bowl: vitreous ceramic Pedestal base: polypropylene
Toilet seat: enameled wood

Dometic VacuFlush 500 series Specifications

General

Brand	Dometic
Model	VacuFlush 500 series
Category	Toilets
Language	English
