25
DO8149
www.domo-elektro.be
EN
PARTS
1. Cover plate
2. Aroma pad
3. Grill
4. Nut
5. Fan blades
6. Large nut
7. Rear grill
8. Motor
9. Two-piece tube
10. Base
11. Control panel with indicator lights
12. Remote control
CONTROL PANEL
13. On/O button
14. Knob for setting speed
15. Oscillation button
9
10
12
11
15
14
13
BEFORE THE FIRST USE
To mount the fan, follow these steps:
1. Place the lower tube on the base. Note the groove in the tube so that it corresponds to the tongue in
the base.
2. Use the supplied screw to screw it into place on the underside of the base.
3. Screw the upper tube with motor onto the lower tube.
1 32
3
4
5
6
7
8
2
1
