22.2 The electrical location diagram for the back door unlocking H30
The front wiring harness
Battery
Engine fuse box
IP_H The instrument wiring harness
D001 Cabin fuse box
D004A The combined instrument Blue
D310B The luggage compartment light
D6260 The back door lock assembly
The back door unlocking switch
The ignition switch
