Donner DDP-80 PLUS - Installation; Piano Stand Installation; Pedal Board Installation; Pedal Socket Installation

1
2
English 02
Piano Stand x 4
Piano Body
Screws M6 x 14 (20PCS)
Pedal Board
Triple-Pedal
Power Adapter
Packing Foam or Soft and Flat Objects
(Tip: Put them under the piano body to prevent
scratching the surface during installation)
3
4
5
6
7
1. Piano stand
installation
2. Pedal board
installation
(If the pedal board cannot
be installed well with the
piano stand, please adjust
the piano stand inward to
align it accurately.)
3. Pedal socket
installation
Ensure that all parts are complete during installation.
The owner and/or operator must read this installation
contents before using the instrument.
Pedal socketAt the bottom of the piano body
7
2
3
1
4
5
6
INSTALLATION
x5
