Donner DED-100 - Connecting Drum and Cymbal Wires

INSTALLATION GUIDE
7
www.donnerdeal.com
Insert the parallel port plug into the
main box as shown in the figure,
and then insert it into the hole
position of the corresponding
striking part according to the
English label on the head of the
connecting line.
06
Insert the connecting wire of drum and cymbal
● Please insert the connecting wire in place to avoid poor contact and insert it
correctly as shown in the figure.
hi-hat
crash ride
tom1 tom2
tom3
snare
control box
Kick drum pedalhi-hat pedal
