2
Electrical Rating GDC6 GDC12
Input AC 230V 50/60Hz
Current ~1A
Power ~200W
Motor
Type DC 24V Brush
Max. capacity 600 Nmm 1000 Nmm
Operation
Lifting capacity 35kg Balanced Door
Travel rate 150mm/s approx.
Door Type
Max. Door Size 14m
2
18m
2
Travel/Force Adjustments Digital controls
Courtesy Light
Light bulb LED array
Lighting time 4.5 minutes
Transmitter
Frequency 433MHz
Operation range 50m (open-field)
Coding type Fixed-code
Battery 12V (A23 Alkaline) x 1
Safety and Features
Soft opening and closing
Safety reverse on closing and stop on opening
Miscellaneous
Operating temperature
-20
o
C to +50
o
C
Dimension (mm) 411 L x 212 W x 175 H
Weight 5kg approx.
Accessories (Optional)
Wall Push Button (Standard / Illuminated / Wireless)
Wireless Keypad
1 / 2 / 3 / 4 Button Transmitters
Safety Photo Eye System
Specification
