Components Identification and Inventory
Fastener (parts in screw bag) Identification
(4)
(10)
(6)
(3)
(4)
(5)
(01) Power Head
(02) Header Bracket
(03) Door Bracket
(04) Door Arm: Curved
(05)C Rail Bracket
(06)Rail Hanging Bracket
(07)Rail-to-Head Bracket
(08) Angle Bracket
(09) Wireless Wall Button
(10) Remote Control
(11) Rail Assembly
(a)Door Arm: Straight
(b)Rope Knob (1 pcs)
(c)Rope (1 pcs)
(b)
(7)
(1)
(2)
(11)
(6)
(10)
(9)
(8)
(7)
Preinstalled on the rail
(c) (a)
(3)
(8)
(5)
(9)
