D439E Service Manual 2. Engine Mechanical System (D439E)
48
12. Install the crankshaft damper pulley (1) and
damper pulley mounting nut (2).
Tightening torque : 588 Nm
(60 kgf.m, 436 Ib-ft)
13. Install the alternator assembly (2).
14. Install the V-belt (1). Adjust the belt tension
using the tension adjusting screw (2) of
alternator.
To Next Page
