D439E Service Manual 2. Engine Mechanical System (D439E)
68
2. Apply the sealant (Loctite #5699) to the rear oil
seal (1), and then install the rear oil seal.
Tightening torque : 7.8 ~ 11.8 Nm
(0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 Ib-ft)
3. Install the rear plate (1).
Tightening torque : 63.7 Nm
(6.5 kgf.m, 47.3 Ib-ft)
4. Install the flywheel (1).
Tightening torque : 39.2Nm + 40°
(4.0 kgf.m + 40°, 29.1 Ib-ft + 40°)
To Next Page
