D439E Service Manual 2. Engine Mechanical System (D439E)
73
14. Remove rear oil seal (1) and oil seal slinger (2).
15. Remove the connecting rod bearing cap (1).
NOTE : Make marks at the connecting rod and cap
to be reassembled correctly.
16. Remove the piston and connecting rod assembly
(1) from cylinder block.
To Next Page
