STEP 9
TWIN BUNK BED
DL7519E / DL7519W
Attach the ladder to the short guardrails (N), the top side rail (H) and bottom side rail (I) with wood
joint connectors (2) as shown.
NOTE: If a slat (L) is covering the ladder mounting holes, remove the slat (L) and reattach it after
the ladder is installed.
Slats are not shown in
illustration for clarity
N
H
I
2
6PCS
2
