KTC-2 (MS9)
9. Change of emergency-stop logic. The ES200 drive will be stopped by
emergency-stop when activated.
The auxiliary contactor N60-0460 must be put on „K1“ contactor.
Normally open K1:53 and 54 to be connected to the terminals –X101:33 and 34 as
follows:
ES200
-X101
