Argus V60 User Guide
PUD4735R1-0
Page 30 support@alvaradomfg.com +1 (909) 591-8431 www.alvaradomfg.com
4.1 Operation modes
4.1.1 Overview of operating modes
4 Operation modes and functions
Symbol Operating mode Description
Free priority Free priority Access is released.
Theunitisaccessibleinbothdirections.The“Freepriority”
operatingmodeisgivenhigherprioritythan“Block”.
Use only to control the STV-ETS. The motor is controlled
without monitoring for functional security.
Block Passage blocked
The door wings block immediately or when they are in home
position (depending on the parameter setting).
General release Door wings can be turned by hand.
Continuous Release Entry Sensors open the door wings in the entry direction and close
them again after each passage.
Continuous Release Exit Sensors open the door wings in the exit direction and close
them again after each passage.
Single Release Entry Door wings open for one passage only, in entry direction.
Single Release Exit Door wings open for one passage only, in exit direction.
Permanently Open Entry The door wings are permanently open in the entry direction.
Permanently Open Exit The door wings are permanently open in the exit direction.
Maintenance Inside The door wings open with Vmin in the parameterized
direction and are then freely movable.
Service outside The door wings open with Vmin in the parameterized
direction and are then freely movable.
Cleaning Inside The door wings open with Vmin in the parameterized
direction and are then freely movable.
Cleaning Outside The door wings open with Vmin in the parameterized
direction and are then freely movable.
