DOTECH FX3S - Parameter Setting Guide; Temperature Setting; Setting 1 Group Parameters; Setting 2 Group Parameters

- 3 -
R20160721
Parameter
Temperature Setting
Parameter Setting
Setting 1 Group
Run mode
FX3S
OUT1
Push for
3 Sec.
Push for
3 Sec.
Compltete Set
FX3S
OUT1
Push for
5 Sec.
T Y P
Select Control Type
C
D I F
Control Deviation Value
1.0
D L T
ON Delay Time
5
0
R T
Minimum OFF Time
N T
Minimum ON Time
5
D T P
Select Deviation Type.
P
U H
Max. Set Point
100
-45
U L
Min. Set Point
D F P
Natural Defrost Cycle
OFF
D F T
Natural Defrost Time
OFF
Setting 2 Group
Run mode
Push for
3 Sec.
Push for
10 Sec.
Lock Function
L O C OFF
Type of Sensor
I N T H 1
Unit of temperature
U N T
oC
Select temp display method.
D P
0. 1
Correct Temp. Sensor
C O R 0.0
Input Filter
F T
0.5
Display Cycle
D T
1.0
Operational Cycle
at error Occurrence.
C L E
OFF
50
Operational Rate
at error occurrence
D U T
FX3S
OUT1
