Parts List
1.Frame 2.Front foot pipe
3.Rail 4.Frame connection
6.Lock bolt set x 2
（one preinstalled on the rail）
5.Front rail cover 7.Seat 8.Rear support
14.Left pedal
13.Long sleeve x 2
(preinstalled on the pedal pipe)
17.M10*55mm
Allen bolt x 2
22.M8 split washer x 8
（Four preinstalled on the
frame connection and four
preinstalled on the rail）
27.M12 lock nut
(preinstalled together)
28.Detent pin
29.Knob bolt
30.M8*20mm
hex bolt x 4
（preinstalled on
the pedal pipe）
31.Big M8 flat
washer x 4
preinstalled on
the pedal pipe）
32.Allen wrench x 2 33.Open end wrench x 4
23.M5*16mm bolt
（Preinstalled on the
rear rail cover）
24.M10*55mm carriage
bolt x 2 (preinstalled
on the rear foot pipe)
25.M10 acorn nut x 2
（preinstalled on the
rear foot pipe）
26.M12*100mm hex bolt
18.M10 flat washer x 4
(Two preinstalled on the
rear foot pipe)
19.M10 split washer x 4
(Two preinstalled on the
rear foot pipe)
20.M8*20mm
Allen bolt x 8
（Four preinstalled on the
frame connection and
four preinstalled on the rail）
21.M8 flat washer x 8
(Four preinstalled on the
frame connection and four
preinstalled on the rail)
15.Right pedal 16.Pedal pipe x 2
10.Rear rail cover
(Preinstalled on the rail)
9.Connecting sheet
(Preinstalled on the rail)
11.Rear foot pipe
12.Short sleeve x 2
(preinstalled on the pedal pipe)
Notice：if any part is missing, distorted or broken when you receive the package, please contact
service@doufit.net with your order number and part number, we will send the replacement part to you as
soon as possible.
Components：
Screw accessories：
（13*15mm）
（17*19mm）
To Next Page
