6
SLICER DESCRIPTION AND CHANGING BLADES
DESCRIPTION
Bread width: 15 inches max.
Bread height: 5 inches max.
Capacity: 240 breads per hour.
Bread slice thickness: 5/8 (optional: 1/2, 3/4 or 1 inch).
Length of the chute: 22 inches.
Motor: 1/4 Hp, 120 Volts, 60 Hz.
Weight: 200 pounds.
TO REMOVE THE BLADES
1. Remove the top cover (9) and the guide (11).
2. Remove the exit chute (10).
3. Remove the support angle on each side of the chute (10) (10mm key).
4. Unscrew bolt (31).
5. Unscrew the bottom bolt on the blade frame.
6. Turn the frame cam wheel (37 and 41) with the v belt.
7. Use the special tool to remove the blades one by one.
TO INSTALL THE NEW BLADES
1. Use the special tool to install the blades one by one.
2. Install the blade frame (25 and 26) tighten the bottom bolt (31) and make sure the frames are
aligned.
3. Install the angle support on each side of the chute (10) (10mm key).
4. Install the exit chute (10).
5. Install the top cover (9) and the guide (11).
