Specifications – Audio Section
HOME
Audio section
Power amplifier
Rated output
Front
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center
90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround back
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Output connector 6 – 16 Ω/ohms
Analog
Input sensitivity/Input impedance 200 mV/47 kΩ/kohms
Frequency response 10 Hz – 100 kHz — +1, –3 dB (Direct mode)
S/N 100 dB (IHF–A weighted, Direct mode)
