DPS MY-PS-3 - DPS Connection Diagram; Voltage Output Check Diagram

DPS CONNECTION DIAGRAM
VOLTAGE OUTPUT CHECK DIAGRAM
4
V W
U V
U W
Output
220V Output
0V
No output
V W
U V
U W
220V 출 력
220V motor
(3 phase)
3 phase
voltage is
applied only
when the
motor is
running.
For reverse
rotation,
swap two
lines of three
output lines.
Circuit breaker
Never use DPS capacity
2 levels
higher than rated motor capacity.
It may cause overheating or trouble.
Output
Input
Input
▶
If the motor is
Not running
▶
When the motor is running
Distribution
Box
5
