Chapter 6: Parts Lists and Schematic Diagrams
Parts List - DR HORIZONTAL/VERTICAL LOG SPLITTER
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 33727 Frame, Main (22 Ton)
33728 Frame, Main (28 Ton)
33729 Frame, Main (34 Ton)
2 33756 Wedge
2.1 36246 Bolt, SHCS, M12-1.75 X 45
2.2 30252 Washer, Flat, M12, ZP
2.3 30253 Nut, Nylon Lock, M12 X 1.75, ZP
3 33700 Bolt, HCS, M16-2 X 69, CL 8.8, ZP
4 30254 Nut, Nylon Lock, M16-2
5 33682 Cylinder, Hydraulic (22 Ton)
33683 Cylinder, Hydraulic (28 Ton)
33684 Cylinder, Hydraulic (34 Ton)
6 33747 Pin, Cylinder Mount
7 33697 Washer, M20
8 33754 Pin, Cotter, 4 X 35mm
9 33715 Hyd Hose Assembly, Valve-Cylinder
10 33749 Guard, Hose, Valve - Cylinder
11 33691 Hyd Adapter
12 33750 Hyd Adapter
13 33742 Valve, Hyd, W/ Control Handle
13.1 36113 Pin, Clevis
13.2 36114 Clip, Hitch
13.3 36249 Link, Connecting, #60 Roller Chain
14 33678 Hyd Hose Assembly, Pump - Valve
15 33695 Hyd Adapter
16 33751 Guard, Hose, Pump - Valve
17 36392 Hose, Hydraulic, 1/2"
18 33752 Guard, Hose, Valve - Tank
19 37768 Isolator, Vibration, Engine (22 and 28
Ton)
37691 Isolator, Vibration, Engine (34 Ton)
20 36390 Fitting, Hyd, 90 Deg Elbow, 1/2" Hose
21 38489 Bracket, Mount, Valve
22 33701 Bolt, HCS, M8-1.25 X 20, CL 8.8, ZP
23 33743 Washer, Lock, M8
24 30247 Washer, M8
25 33696 Hyd Adapter
26 33739 Hyd Pump (22 and 28 Ton)
33740 Hyd Pump (34 Ton)
27 33681 Coupling, Shaft
27.1 33679 Coupling, Shaft, 3/4" Bore
Ref# Part# Description
27.2 33680 Coupling, Shaft, 1" Bore
28 33716 Set Screw, M6-1 X 10
29 33753 Spider, Coupling, Shaft
30 33730 Mount, Pump, Hyd (22 and 28 Ton)
33731 Mount, Pump, Hyd (34 Ton)
31 33701 Bolt, HCS, M8-1.25 X 20, CL 8.8, ZP
32 30247 Washer, M8
33 33743 Washer, Lock, M8
34 13286 Bolt, HCS, 5/16-24 X .75, Gr5, ZP
35 30247 Washer, M8
36 11243 Washer, Lock, M8
37 33725 Key, Square, 3/16 X 1.75
33726 Key, Square, 1/4 X 2.165
38 33698 Engine, Kohler 6.5, MS (22 and 28 Ton)
36394 Engine, 14.5 B&S, MS (34 Ton)
39 33702 Bolt, HCS, M8-1.25 X 40, CL 8.8, ZP (22
and 28 Ton)
36110 Bolt, HCS, M10 x 40 (34 Ton)
40 30247 Washer, M8 (22 and 28 Ton)
30250 Washer, M10 (34 Ton)
41 30246 Nut, Nylon Lock, M8-1.25 (22 and 28
Ton)
30249 Nut, Nylon Lock, M10-1.5 (34 Ton)
42 37692 Reservoir Tank (22 and 28 Ton)
37693 Reservoir Tank (34 Ton)
43 33685 Dipstick
44 33744 Oring, 15 X 3.1mm
45 33746 Plug, Drain,
46 33745 Oring, 20 X 2.4mm
47 33693 Filter, Hyd, Intank
48 33736 Hyd Hose Assembly, Reservoir - Pump
49 33713 Hose Clamp, 1"
50 35476 O-Ring, 11mm X 2mm
51 35478 O-Ring, 19mm X 2.5mm
52 33689 Support, Fender,
53 33703 Bolt, HCS, M8-1.25 X 25, CL 8.8, ZP
54 30247 Washer, M8
55 30246 Nut, Nylon Lock, M8-1.25
56 33688 Fender,
57 33762 Wheel
58 25310 Nut, Slotted, 1-14, ZP
