DR 22-Ton - Page 32

32 DR
®
HORIZONTAL/VERTICAL LOG SPLITTER
Parts List – DR HORIZONTAL/VERTICAL LOG SPLITTER (continued)
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
59 33755 Pin, Cotter, 4 X 50mm
60 33714 Cap, Dust,
61 33748 Pin, Spring, 3 X 30mm
62 33718 Lock, Safety, Vertical Position
63 33757 Spring, Vertical Safety Lock,
64 30250 Washer, M10
65 33704 Bolt, HCS, M10-1.5 X 20, CL 8.8, ZP
66 33758 Pin, Hitch, 2.5mm
67 33676 Bolt, HCS, M8-1.25 X 20, CL 8.8, ZP
68 33705 Bolt, HCS, M10-1.5 X 80, CL 8.8, ZP
69 30250 Washer, M10
70 30249 Nut, Nylon Lock, M10-1.5
71 33737 Towbar
72 33712 Bracket, Horizontal Beam Lock,
73 33705 Bolt, HCS, M10-1.5 X 80, CL 8.8, ZP
74 30250 Washer, M10
75 30249 Nut, Nylon Lock, M10-1.5
76 33717 Stand, Jack,
77 33705 Bolt, HCS, M10-1.5 X 80, CL 8.8, ZP
78 30250 Washer, M10
79 30249 Nut, Nylon Lock, M10-1.5
80 33677 Pin, Clevis, 10 X 70mm
81 33759 Pin, Hitch, 3.0mm
82 33711 Receiver, 2", Class Ii,
83 33734 Chain, Safety, Pair
84 33706 Bolt, HCS, M12-1.75 X 80, CL 8.8, ZP
85 30252 Washer, M12
86 30253 Nut, Nylon Lock, M12-1.75
87 37171 Tray, Log, WH1
Ref# Part# Description
87.1 36087 Bolt, HCS, M10 X 30, CL8.8, ZP
87.2 30250 Washer, M10
87.3 33343 Nut, Nylon Lock, Flanged, M10-1.5
87.4 33721 Support 1, Tray, Log
87.5 33722 Support 2, Tray, Log
87.6 33723 Endplate, Tray, Log
88 33707 Bolt, HCS, M12-1.75 X 45, CL 8.8, ZP
89 30252 Washer, M12
90 30253 Nut, Nylon Lock, M12-1.75
91 33686 Bracket, Retraction Stop, RH,
91.1 33687 Bracket, Retraction Stop, LH,
92 35599 Bolt, HCS, M12-1.75 X 35, CL 8.8, ZP
93 30252 Washer, M12
94 30253 Nut, Nylon Lock, M12-1.75
95 33708 Bolt, HCS, M10-1.5 X 30, CL 8.8, ZP
96 30250 Washer, M10
97 30249 Nut, Nylon Lock, M10-1.5
98 38486 Handle, Actuation
99 38487 Lever, Return, Handle
100 38488 Spring, Return, Handle
101 38490 Bolt, HCS, W/ Hole, M8-1.25 X 20, CL
8.8, ZP
102 38491 Bushing, 8mm ID
103 35477 O-Ring, 16mm X 2.5mm
104 36103 Nut, Finish, M8 X 1.25, ZP
Not Shown
33365 Label, 22 Ton Branding
33366 Label, 28 Ton Branding
33367 Label, 34 Ton Branding
33368 Label, Operation
33457 Label, Warning, Towbar
