DR 22-Ton User Manual

CONTACT US AT w w w .DRpow er.com 7
Horizontal
Beam Lock
J
ack Stan
d
Hitch
Receiver
Control Handle
Splitting Wedge
Log Dislodger
Cylinder
End Plate
Log Tray
Vertical
Beam Lock
Hydraulic Oil
Reservoir
Road Tow
Wheels
Hydraulic Oil
Fill/Check
Hydraulic
Pump
Chapter 2: Assembly and Setting Up The DR HORIZONTAL/VERTICAL LOG SPLITTER
It may be helpful to familiarize yourself with the controls and features of your DR HORIZONTAL/VERTICAL LOG SPLITTER as
shown in Figure 2 before beginning these procedures. If you have any questions at all, please feel free to contact us at
www.DRpower.com.
DR HORIZONTAL/VERTICAL LOG SPLITTER Controls and Features
Figure 2
Fuel Shut-off
Valve
Choke
Control
Leve
r
Throttle Control
Lever
Recoil Starter
Handle

DR 22-Ton Specifications

General

Brand	DR
Model	22-Ton
Category	Log Splitter
Language	English
